For energy-efficient precast walls.Schöck Isolink® for concrete façades.

The Schöck Isolink® is the energy-efficient alternative to conventional stainless steel dowels when connecting the concrete layers of core-insulated sandwich panel walls.

read more
ILU_IL_Produktmotiv_Isolink_Betonfassade_16z9_FHD_21RL

Dependable thermal insulation

As a ‘Certified Passive House Component’, Schöck Isolink® guarantees dependable thermal separation in core-insulated concrete façades. This is due to the exceptionally low thermal conductivity of Combar® glass fibre composite from Schöck.

High functionality and safety

Schöck Isolink® also acts as a connector and spacer between the concrete layers within the wall. It is suitable both for supported and self-supporting façades and facilitates large-scale panel sizes  up to 6 x 12 m before an expansion joint is required. All Schöck Isolink® product types for concrete façades have been tested and approved by the German Institute for Structural Engineering (DIBt).

Easy to install with all insulating materials

Compact and easy to install, Schöck Isolink® also improves cost efficiency when prefabricating concrete building components The round bar is easy to insert into the thermal insulation layer. It is a system that is suitable for any core-insulated wall.

For high-end exposed concrete façades

The product types with „depth stop“ (C-SH and C-SD) enable the construction of high-end exposed concrete façades.

Downloads
Brochures
Brochure Schöck Isolink® for concrete facades
pdf, 1,31 MB
(08/05/2024)
Technical manuals
Design tables Schöck Isolink® for insulated precast concrete walls
pdf, 1,50 MB
(05/04/2021)
Approvals
European Technical Assessment Schöck Isolink® for multi-layer concrete panels – ETA 17/0773
pdf, 5,80 MB
(12/18/2023)
Certificates
Environmental Product Declaration EPD Schöck Isolink®
pdf, 1,42 MB
(09/15/2021)
Certificates
Certificate Passive House Institute: Certified Passive House Component Schöck Isolink® type C
pdf, 176,94 KB
(03/06/2024)
Certificates of conformity
Certificate of conformity Schöck Isolink® type C
pdf, 33,21 KB
(07/21/2022)
