Schöck Tronsole® type Z

Schöck Tronsole® type Z enables acoustically insulated connections between landings and staircase walls (brick or concrete). Acoustic separation for optimum reduction of impact sound. The excellent impact sound insulation eliminates the need for floating screed on intermediate landings. So structures can be slimmer, and construction workflows faster.

read more
Schöck Tronsole® type Z: Impact sound insulation element for connecting landings to staircase walls.
Benefits
  • Schöck Elodur® elastomer support
    Ensures an impact sound level delta of ∆Lw* ≥ 27 dB to ∆Lw* ≥ 33 dB on all products, tested to DIN 7396.
  • Suitable for emergency exits
    Confirmed in the fire safety certificate
  • Type-approved supporting element
    With spacers for safe and simple installation.
  • Enhanced flexibility
    Additional types available for uplifting forces and horizontal forces
  • Uninterrupted joint pattern
    Once installed, Tronsole® type Z disappears from sight under any landings that are 180 mm or higher
  • Surrounding connection frame
    For connection to Tronsole® type L-250 joint panel without acoustic bridges
  • Fire resistance class R90
    Complies with the requirements for fire resistance class R90 (subject to use of Z Part T supporting element)
Staircase systems
+ + + +

Type T-V4

Type T-V4

Type L

Type Z

Schöck Tronsole® type Z: Impact sound insulation element for connecting landings to staircase walls.
Tronsole® type Z

Impact sound insulation element for connecting landings to staircase walls.

Go to type Z

Schöck Tronsole® type L: For insulating impact sound at the joint between stairs and wall
Tronsole® type L

For insulating impact sound at the joint between stairs and wall.

Go to type L

Impact sound insulation element for connecting staircases to landings with a straight joint
Tronsole® type T-V4

Impact sound insulation element for connecting staircases to landings with a straight joint.

Go to type T

Straight staircase, insulated stairs and landing
Acoustic insulation of stairs to landing using Schöck Tronsole® type T, of landing to wall using Tronsole® type Z. Tronsole® type L insulates stairs to wall. This produces the blue line around the acoustically insulated staircase – a seal of quality for superior impact sound insulation.
Straight staircase, insulated stairs and landing
Straight staircase, insulated stairs and landing

Impact sound insulation element for connecting landings to staircase walls.

Go to type Z

For insulating impact sound at the joint between stairs and wall.

Go to type L

Impact sound insulation element for connecting staircases to landings with a straight joint.

Go to type T

Elastomer bearing

Schöck Elodur® is an elastomer bearing that was developed specifically for impact sound insulation. It is the key component in Schöck Tronsole®. In the case of the Tronsole® type Z, the Elodur® serves as a point connection. Depending on the required load transfer, the wall element can absorb horizontal forces in addition to positive and negative shear forces. For this purpose, the number of Elodur® elastomer bearings in the wall element can be adjusted. Unlike conventional impact sound insulation supports, Schöck Tronsole® achieves an improvement of about 10 dB in impact sound insulation performance by using the elastomer support, Schöck Elodur®. This is approximately equivalent to about half the perceived loudness level.

Downloads
Technical manuals
Technical Information Schöck Tronsole® type Z
pdf, 11,73 MB
(09/04/2020)
